Woods RB990

Double tap to zoom

9-foot moldboard length
Tractor HP range: 80-150 hp
Three-point hitch: Cat 2 and 3
Available as fully hydraulic, fully manual or a combination of cylinder options
Fully hydraulic models allow precise blade and material control (angle, tilt and offset)
Tough, dozer-type full box construction
Optional end plates, kid shoes and tail wheel
Standard parking stand for added convenience

Tractor hitch	Cat 2 & 3
Tractor Engine HP	80 - 150 hp
Working width	107"
Moldboard height	18"
Moldboard thickness	.25"
Approximate weight	1,483 lbs
Pivot angle	up to 60° each side fwd / up to 60° each side rev
Tilt	up to 28°
Offset	up to 23.5" left or right
End plates	-
Skid shoes	-
Tailwheel	optional
ASABE quick-hitch compatible	yes
Parking Stand	standard
