Woods BB72.50

Double tap to zoom



Features

  • 72-inch wide cutter for 30-150 hp tractors cuts brush up to 3 inches in diameter.
  • Quick-hitch compatibility and a drive lift hanger make it easy to attach.
  • Exclusive, greasable Quick-change pins and a large access window on top of the deck make it quick and easy to change blades.
  • Rugged bumper has Z-channel frame for added durability when backing over brush.
  • Large .5 x 4-inch blade increases suction and lifts material, resulting in excellent cut quality.
  • Smooth, sloped, clutter-free deck is easy to clean.

Specifications

Model BB72.50
PTO Horsepower 30-150 hp
Hitch category / type CAT 1 & 2 clevis
Cutting width 72"
Total Weight (lbs) 1,125
Cutting capacity diameter 3"
Cutting height 2" - 12"
Transport width 79.3"
Overall length 112"
Tractor PTO Speed (rpm) 540
Quick-hitch compatible yes
Rear bumper Z-channel
Frame & deck support 3" x 3" tube
Deck Construction smooth top, sloped
Skid shoes full-length, replaceable
Deck Tilt/Height Adjust 10 ga (.250")
Side frame thickness 10 ga (.135")
Side frame depth 12.7"
Gearbox warranty 6-year limited
Gearbox HP 150 hp
Output shaft diameter 2"
Blade tip speed 15,900 fpm
Blade dimensions .50" x 4"
Blade pin diameter 1.5"
Blade carrier diamond stump jumper, optional round
Driveline protection slip-clutch
Options check chains, round stump jumper, dual tailwheel
