Woods CP24

Double tap to zoom



  • 24-inch cutting width
  • Cutting depth range: 0-6 inches
  • Manual controls attach to any skid steer
  • Top pivot design to self-level drum and chassis for higher down force and smoother cuts
  • Optional water kit for increased longevity
  • Optional step drum and stripe removal drum for added versatility


Hydraulic flow classification high-flow
Working width 24" (609.6 mm)
Depth of cut 0-6" (0-152.4 mm)
Number of teeth 62
Side shift (right) 0-22" (0-558.8 mm)
Tilt +/- 15°
Hydraulic flow requirement 28 - 32 gpm (106 - 121 lpm)
Hydraulic pressure requirement 2,200 - 3,500 psi (152-241 bar)
Operating weight 1,919 lbs (872 kg)
Depth control mechanism hydraulic
Tilt control mechanism hydraulic
Side shift mechanism hydraulic
Hydraulic function activation means manual or electric
