Woods SG60B

Double tap to zoom

Grinds stumps 28-inches above and 16-inches below ground
Hydraulic requirements: flow 30-42 gpm, pressure 2,000-5,000 psi
Telescoping head for less repositioning
24 Sandvik teeth on a 19.5-inch cutting wheel
Choose manual or electro-hydraulic controls to easily manage swing, depth and extension

Overall length	64.1" (1,628.1 mm)
Telescopic extension	14" (355.6 mm)
Output torque	213 - 533 lbs-ft (29-74 kg-m)
Cutting height above ground	28" (711.2 mm)
Cutting height below ground	16" (406.4 mm)
Cutting wheel width	3.52" (89.4 mm)
Working width	19.5" (495.3 mm)
Cutting wheel speed	865 - 1,325 rpm
Swing range	+/- 45°
Max. stump diameter capacity	32" (813 mm)
(without re-positioning)
Type of teeth	Sandvik
Number of teeth	24
Operating weight	887 lbs (403 kg)
Driveline	piston motor and planetary
Hydraulic flow requirement	30 - 46 gpm (114-174 lpm)
Hydraulic pressure requirement	2,000 - 5,000 psi (138-345 bar)
