J&M Manufacturing TF212

New Equipment / All Brands / J&M Manufacturing / Soil Conditioners / 3 Section Models / TF212



Features

Premium GBGI Bearings

Heavy-duty GBGI bearings feature a sealed, cast hub-style housing with double roller bearings for extra durability to handle more side thrust and a heavier workload. The rubber-sealed hub caps and 3 piece "V seal" are optimal for keeping dirt and contamination away from the bearings during high speed usage. Snap rings hold the seals in place while allowing the bearings to be serviceable at a lower cost than replacing the entire assembly.

Turnbuckle Design

Engineered to maximize transport ground clearance... regardless of the hitch height.

Heavy Duty Hinges

Hinge areas feature oversized folding cylinders, heavy duty over-center linkage plates and extra thick, reinforced hinges with large 1¾" diameter pins.

Lighting Package

Deluxe light kit includes SMV emblem for safe transport.

More Standard Features

  • Two rows of standard 13" diameter baskets with Double-Twist serrated bar design
  • 11L-15 new tires
  • Extendable tongue
  • Rear storage jack

Specifications

Working WidthTransport WidthBase
Width		Wing Width (Each)Weight (13" Baskets)
20'13'–5"12'4'4,415 lbs
22'13'–5"12'5'4,645 lbs
23'13'–5"12'5'4,760 lbs
24'13'–5"12'6'4,875 lbs
26'13'–5"12'7'5,105 lbs
27'13'–5"12'7'5,220 lbs
28'13'–5"12'8'5,235 lbs
29'13'–5"12'8'5,450 lbs
30'13'–5"12'9'5,565 lbs
31'13'–5"12'9'5,680 lbs
32'13'–5"12'10'5,795 lbs
33'13'–5"12'10'5,910 lbs
34'13'–5"12'11'6,025 lbs
35'13'–5"12'11'6,140 lbs
