John Deere HP21 Hydraulic Power Pack

New Equipment / John Deere / Agriculture / Attachments Accessories and Implements / Utility Tractor Attachments and Implements / Frontier™ Loader Attachments / HP21 Hydraulic Power Pack

Features
Specs and Compare

Features

Thermal switch protects hydraulic system

Protective thermal switch

A thermal switch protects the hydraulic system when the hydraulic oil reaches 93 °C (200 °F).

Rear quick connect makes hookups convenient

Convenient hydraulic hookup

Rear quick connect makes for fast and easy connections.

Optional oil cooler unit

Oil cooler unit

The optional oil cooler unit regulates the temperature of the hydraulic fluid for warmer weather implements.

Key Specs

Unit width	965 mm 38 in.
Unit width with weights	1,524 mm 60 in.
Unit height	1,321 mm 52 in.
Unit length	762 mm 30 in.
Counter weight support	700, accepts John Deere weights: 19.1 kg 42 lb and 31.8 kg 70 lb
Hitch - Category	Category 1 and 2
Quick hitch, Category 2	Yes
PTO horsepower	26.1-41.8 kW 35-56 hp
PTO rpm	540 rpm
Loader (current John Deere series)	400

Dimensions

Unit width	965 mm 38 in.
Unit width with weights	1,524 mm 60 in.
Unit height	1,321 mm 52 in.
Unit length	762 mm 30 in.

Weight

Operating	1,177 kg 535 lb
Shipping	1,177 kg 535 lb

Tractor requirements

PTO horsepower	26.1-41.8 kW 35-56 hp
PTO rpm	540 rpm
Loader (current John Deere series)	400

Hitch

Category	Category 1 and 2
Quick hitch, Category 2	Yes

Hydraulics

Relief valve setting	207 bar 3,000 psi
Oil cooler	Standard
Flow @ 3000 psi (207 bar)	75.7 L/min 20 gpm
Oil reservoir	56.8 L 15 U.S. gal.
Hose diameter	19 mm 0.75 in.
Tank-mounted strainer	Standard
Tank-mounted return filter	Standard, with breather
Pump rpm	1,836 rpm

Miscellaneous

Parking stands	Standard
Counter weight support	700, accepts John Deere weights: 19.1 kg 42 lb and 31.8 kg 70 lb

Shipping

Configuration	One unit

Set-up time

Labor hours	1.5-2

Warranty

Time period (machine)	1 year
